A young company with 40+ years of engineering vintage. Sanlayan moves at startup speed and ships with the certainty of four decades on India's frontline platforms. Vertically integrated defence electronics, from modules to mission ready systems.
CapabilitiesSanlayan By The Numbers
Built on 40+ years of engineering vintage, moving at startup speed. Sanlayan is pioneering rapid technology development and deployment for India's most mission critical needs.
Core Capabilities
Six verticals, one integrated stack. RF systems, sensors, mission electronics, secure links, embedded computing and ruggedised power, built for mission critical defence applications by people who have shipped every layer.
Radar warning receivers, wideband jammers, ESM and ECM suites and directed countermeasures for airborne, naval and land platforms, designed for the contested spectrum of modern conflict. Includes the drone mounted ultra wideband HPM system delivered to DRDO.
AESA based fire control, surveillance and counter UAS radars with indigenous T/R modules, planks, tiles, GaN SSPAs, signal processing and trackers, built for every domain and altitude with 100+ concurrent tracks.
CEMILAC qualified mission computers, multi function displays, engine flight display units and certified airborne software for fighters, helicopters and UAVs.
OFDM modems, datalinks and rugged military grade Ethernet switching delivering encrypted, anti jam connectivity across the tactical edge.
Rugged VPX computing from Atom to Xeon and GPGPU, RFSoC and Versal processing, DRFM, digital receivers, I/O cards and ATE that anchor the entire stack.
The quiet backbone of every sensor, jammer and mission computer. Four decades of Indian market leadership across the complete power chain, from 500W DC to DC modules inside manpack radios to 120kW shipboard rectifiers, scalable to 1000kW.
Our Industries
From modules to mission ready systems, Sanlayan brings depth, scale and precision across all layers, actively shaping the vision of a self reliant Bharat.
Mission computers, displays and certified airborne LRUs for fighters, helicopters and UAVs.
Shipboard power, sensors and electronics for carriers, frigates and submarines.
Radar, EW and power conversion for tanks, AD guns and ground based radars.
Seeker electronics, launcher power and timing systems for guided weapons.
Qualified electronics and simulators supporting ISRO and space programs.
Product Catalogue Highlights
A selection from the Sanlayan catalogue. Every product is backed by in house design authority, certified manufacturing and lifetime sustainment.
Intel Xeon 6518P with 20 performance cores and 256GB DDR5 ECC memory for demanding signal processing loads.
2x XMCLinux, VxWorks, Windows
Icelake D and Atom class boards in air cooled and conduction cooled builds for SWaP constrained platforms.
Up To 64GB DDR4XMC Expansion
Third generation RF system on chip with quad core ARM and 8 or 16 channel 14 bit ADC and DAC.
ZU43/47/49 DRLinux & Baremetal
NVIDIA RTX 5000 class GPU with 10496 CUDA cores and 24GB GDDR7 with ECC for AI at the tactical edge.
320 Tensor Cores2x Video Out
Two Versal Premium adaptive SoCs with dedicated high speed interconnects and 32 lane PCIe Gen4 expansion.
Up To VP1702VITA 66 Backplane
Rackmount and turbo switches with up to 28 ports, 10G optics, IEEE 1588 PTP, MACsec and secure boot.
MIL GradePoE+L3 Routing
Architecture and hardware developed fully in India. Low noise figure, ITAR free design with high transmit and receive gain.
7 Bit Phase6 Bit Attenuation
32 channel plank under 1.6kg integrating front end switch, PA, LNA, RF distribution and power on a single PCB.
Blind MateAutomated Production
16 channel tile with analog phased array beamforming ICs, 10 GHz lattice spacing and fail safe bias control.
ScalableBuilt In Calibration
Software defined X Band pulse Doppler AESA with 4D processing, AI target classification and 100+ concurrent tracks.
Nano UAV 5kmFighter 40km
Advanced GaN amplifiers from 200 MHz to X Band, spanning 25W CW wideband units to 1000W pulsed L Band.
L, S, X & WidebandUp To 1kW
RF sweep generation for S Band radars with configurable DAC sampling clocks from 1.8 to 7.2 GHz.
LO 2.8 To 3.3GHzExt Sync 120MHz
Electronic support measures, radar warning receivers and direction finding systems for spectrum awareness.
Search & Monitoring Receivers
RF tuners, multi channel exciter receiver processors and digital receivers on RFSoC and MPSoC class boards.
Zynq UltraScaleWideband
Wideband jammers, beamforming units, wideband TR modules and power amplifiers for active countermeasures.
Self Protection Class
Drone mounted high power microwave system delivered to DRDO, with pulser integrated antenna and battery operation.
Counter Drone Trials At 100m
Field proven C UAS integrating passive detection, RF jamming and command and control, validated in real world trials.
Detection + Jamming Validated
AI and ML based signal processing, target classification and multi sensor data fusion for faster decisions.
30+ Member Software & AI Team
CEMILAC qualified computer with high precision symbol generation for HUDs and MFDs and real time video overlay.
MIL STD 1553BARINC 429VxWorks 7
High resolution LCD with saturated colour in day and NVG modes, glove compatible resistive multi touch.
1024 x 768Rugged Lightweight
Switches four composite video inputs to eight outputs with built in audio mixing and uninterrupted feed on power loss.
HD SDI 1 To 4 Distribution
Processes multiple analog sensor signals for onboard display and manages data buses with internal health management.
EFDU Modules
XMC MIL 1553B plus ARINC cards with dual redundant channels and eight programmable ARINC 429 channels.
VITA 42.0BC, RT, BM Modes
DAL A to E compliance with full certification package development and stage of involvement audits.
PSAC, SDP, SVP, SCMP, SQAP, SAS
Ruggedised Power SolutionsThe Quiet Backbone
Power is the quiet backbone of every sensor, jammer and mission computer. Sanlayan designs and manufactures the complete power chain: from 500W DC to DC modules inside manpack radios to 120kW rectifiers feeding battleship systems. Every unit is qualified to MIL STD 704, MIL STD 810 and JSS 55555, engineered with redundancy, hot pluggable modules and hold up performance that mission critical loads demand.
Scalable To 1000kWEfficiency Above 95%PFC Above 0.99
AirborneFighter Aircraft
HVPS pulse and CW units for jammers, DC to DC MOPS for active phased arrays and 40kW electrical distribution control panels.
Up To 40kW270V DC115V AC 400Hz
AirborneRadars
Active array power supply units, DC to DC PSUs delivering 50V at 240A for TR modules and airborne transmitters for weapon radars.
Up To 15kWTR Module Class
Seekers & Missiles
Launcher power supply and relay units with 100ms hold up plus EPCs for travelling wave tubes at 4.2kV.
1kW To 3kW4.2kV EPC
ArmyAD Guns & Tanks
Solid state DC to AC converters for battle tanks, battery chargers, inverters and 10kW step up converters for armoured platforms.
500W To 10kW18 To 36V DC Input
ArmyGround Radars
DTRM power supplies with full redundancy, antenna PSUs for phased arrays and 20kW to 30kW rectifier units with hold up.
Up To 30kW100% Redundancy Options
NavyBattleships
Low voltage power supply units up to 25kW and 120kW AC to DC rectifiers, with active rectifier modules scalable to 1000kW.
Up To 120kWScalable To 1000kW
High Voltage
Pulse and CW high voltage supplies with cathode outputs to 11kV for airborne jammer travelling wave tubes.
Up To 3kW Peak115V AC 400Hz
Programmable
Programmable 200 to 1000V DC output, above 95% efficiency, hot pluggable redundant modules, scalable to 1000kW.
PFC Above 0.9920kgValidated
Platforms & Systems We Have Powered
Mission critical solutions developed and deployed across tri services, from frontline fighters and carriers to radars and guided weapons. This is not a roadmap. It is a service record.
Certifications
